2.5mm 12 AWG 18 AWG Electric Cable Wire PVC Insulated Copper Single Core Cable

Brand Name : Minfeng

Model Number : BV cable

Certification : ISO,CE,IEC,TUV,KEMA

Place of Origin : Hebei, China

MOQ : 100

Price : 0.1-5

Payment Terms : L/C,T/T

Supply Ability : 100KM/Week

Material : PVC Copper

Conductormaterial : Copper

Flame Retardant : As per customer request

Application : Building wiring, electrical installations

Meterial : Solid/Stranded Copper

Jacket Material : PVC

Operating Temp : 70 degree

Cable Spec : 1.5sqmm,2.5sqmm,4sqmm ,6sqmm to 400sqmm

Contact Now

2.5mm 12 AWG 18AWG PVC Single Core Copper Electric Wire Cable
Product Overview
Product Name: Copper core PVC insulated non-sheathed cable
Standard: GB/T5023-2008 (Equivalent to IEC 60227-1997)
Conductor: Copper
Insulation: PVC
Color Options: red, yellow, blue, green, black, white, brown, two-color (yellow-green)
Model: BV, BVR
Available Specifications: 0.75mm², 1mm², 1.5mm², 2.5mm², 4mm², 6mm², 10mm², 16mm², 25mm², 35mm², 50mm², 70mm², 95mm², 120mm², 150mm², 185mm², 240mm², etc.
Rated Voltage: 300/300V; 300/500V; 450/750V
Applications: Socket connection line, lighting, switch, air conditioner, distribution box, building wiring, etc.
Service Performance
  • Long-term working temperature: not higher than 70°C
  • Minimum ambient temperature during installation: not lower than 0°C
  • Minimum bending radius: ≥ 4D for cable overall diameter ≤ 25mm; ≥ 6D for cable overall diameter > 25mm
2.5mm 12 AWG 18 AWG Electric Cable Wire PVC Insulated Copper Single Core Cable2.5mm 12 AWG 18 AWG Electric Cable Wire PVC Insulated Copper Single Core Cable
Model Comparison
BVR: Multi-core copper wire, soft, easy to install, lower strength. Generally used in applications with slight movement.
BV: Single-core copper wire, hard, more difficult to install, higher strength. Generally used in fixed installations.
2.5mm 12 AWG 18 AWG Electric Cable Wire PVC Insulated Copper Single Core Cable
Wire Selection Guide
  • Lighting circuits: Generally use 1.5 square single core hard wire (BV1.5), with live and neutral wires distinguished by color
  • Socket circuits: Generally use 2.5 square single-core hard wires (BV2.5)
  • Air conditioners above 3 HP: Generally use 4 square (BV4) or larger single-core wires
  • Main home bus: Generally use 6 square (BV6) or larger single-core wire
  • Consult online customer service for specific configuration and quantity requirements
2.5mm 12 AWG 18 AWG Electric Cable Wire PVC Insulated Copper Single Core Cable2.5mm 12 AWG 18 AWG Electric Cable Wire PVC Insulated Copper Single Core Cable2.5mm 12 AWG 18 AWG Electric Cable Wire PVC Insulated Copper Single Core Cable2.5mm 12 AWG 18 AWG Electric Cable Wire PVC Insulated Copper Single Core Cable
Electrical Wire Specifications
ModelVoltage Level (V)Cross-sectional Area (mm²)Number/Diameter (mm)Outer Diameter (mm)Weight (kg/km)20℃ Conductor Resistance ≤ (Ω/km)
BV300/500V0.51/0.802.48.536
BV300/500V0.75 (A)1/0.972.611.124.5
BV300/500V0.75 (B)7/0.372.81224.5
BV300/500V1.0 (A)1/1.132.813.918.1
BV300/500V1.0 (B)7/0.4331518.1
BV450/750V1.5 (A)1/1.383.320.312.1
BV450/750V1.5 (B)7/0.523.521.612.1
BV450/750V2.5 (A)1/1.783.931.67.41
BV450/750V2.5 (B)7/0.684.234.87.41
BV450/750V4 (A)1/2.254.447.14.61
BV450/750V4 (B)7/0.854.850.34.61
BV450/750V6 (A)1/2.764.967.13.08
BV450/750V6 (B)7/1.045.471.23.08
BV450/750V107/1.3571191.83
BV450/750V167/1.7081791.15
BV450/750V257/2.14102810.727
BV450/750V357/2.5211.53810.524
BV450/750V5019/1.7813.05210.387
BV450/750V7019/2.14157340.268
BV450/750V9519/2.5217.59620.193
BV450/750V12037/2.031911800.153
BV450/750V15037/2.252114700.124
BV450/750V18537/2.5223.518100.0991
BVR450/750V2.519/0.414.234.77.41
BVR450/750V419/0.524.851.44.61
BVR450/750V619/0.645.673.63.08
BVR450/750V1049/0.527.61291.83
BVR450/750V1649/0.648.81861.15
BVR450/750V2598/0.58113060.727
BVR450/750V35133/0.6812.54030.524
BVR450/750V50133/0.6814.55530.387
BVR450/750V70189/0.6816.57640.268
Technical Specifications
Nominal Sectional Area mm²Conductor No/Dia. mmNominal Insulated Thick mmMax Overall Dia. mmConductor Resistance at 20℃Min Insulated Resistance at 70M Ω/kmWeight Kg/km
1.51/1.380.73.312.10.01119.2
1.57/0.520.73.512.10.0120.6
2.51/1.780.83.97.410.0130.8
41/2.250.84.44.610.008545.5
61/2.760.84.93.080.00765
107/1.35171.830.0065110
167/1.70181.150.005170
257/2.141.2100.7270.005270
357/2.521.211.50.5240.004364
5019/1.781.4130.3870.0045500
7019/2.141.4150.2680.0035688
9519/2.521.617.50.1930.0035953
12037/2.031.6190.1530.00321168
15037/2.251.8210.1240.00321466
18537/2.52232.50.0990.00321808
